YVF160M-4 VVVF Three-phase Asynchronous Motor 380 V

Brief Introduction

The YVF160M-4 motor 380 v, a flagship model of SIMO's YVF series of variable-speed three-phase asynchronous motors, is purpose-built to meet the demands of modern industrial operations, from material handling and process automation to HVAC and manufacturing machinery. Designed by SIMO MOTOR -a leader in industrial motor technology-this motor combines intelligent performance with rugged durability to deliver a reliable, cost-effective solution for businesses aiming to boost productivity and reduce operational costs.

At the heart of the YVF160M-4 is its advanced variable voltage variable frequency (VVVF) technology, which enables smooth, precise speed adjustment across an extended frequency range. Unlike fixed-speed motors, this allows the YVF160M-4 to adapt seamlessly to fluctuating load demands, eliminating energy waste during partial-load operation and delivering significant long-term savings on electricity bills. Whether powering a conveyor that requires gentle acceleration or a fan that needs variable airflow, the motor maintains consistent torque output and operational stability, reducing wear on connected equipment and extending the lifespan of the entire system.

Built to thrive in harsh industrial environments, the YVF160M-4 motor 380 v features an IP55-rated enclosure that provides robust protection against dust, water spray, and other contaminants, ensuring reliable performance even in dirty or damp conditions. Its Class F insulation system withstands continuous high temperatures up to 155°C, while the IC 416 external fan cooling system efficiently dissipates heat to maintain thermal stability during 24/7 S1 duty cycles. The motor's B3 foot mounting design ensures secure, vibration-dampened installation, reducing noise and minimizing stress on both the motor and its base, while heavy-duty 6309/C3 bearings deliver exceptional durability and low maintenance requirements.

Compliant with JB/T7118 industry standards and CE certified, the YVF160M-4 motor 380 v is a trusted choice for global industrial applications. Its compact, space-saving design and flexible speed control make it easy to integrate into existing systems, while SIMO's reputation for quality and after-sales support ensures peace of mind. For businesses seeking a motor that balances efficiency, reliability, and adaptability, the YVF160M-4 stands out as a versatile, future-ready solution that drives operational excellence.

Main Technical Parameters

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC installation dimensions available

• Customizable outlook and dimensions

---

Stator

• 99.9% pure copper winding for stator to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the windings are fitted in by handwork to ensure all slots are full and avoid any winding flaw.

---

Rotor

• Aluminum casting rotor with high quality silicon steel rotor core to assure induction efficiency

• Well and precisely machined shafts with good capacity of strength and toughness

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

Cement

Chemistry

Pump

Water conservation
